Computer
Automatic Dry Cleaning Machine' (MTG) can be installed in laundries where the structure is able to fully support the static weight of a fully loaded machine. The machines feature super high-speed extraction speeds with over 300 to 4006 force through a highly efficient inverter with single motor drive setup. State-of-the-art software HMI Touch screen microprocessor..
Drive
Efficient Drive System Equipped with inverter. the machine has the advantages of energy savings as it reduces the peak energy demand and facilitate stable running. Four kinds of speeds in washing can be obtained such as washing, distributing. middle -speed and high- speed extracting can be obtained.
Tank / Pump
Two automatic self cleaning tanks of high capacitySeparate tanks for light & dark shade solvent. Solenoid operated drains. Separate pumps inject the solvents into their respective filters for re-use. Intake of fresh solvent by pump.
Filter
Nylon self cleaning filter or cartridge with active carbons
Fabricated/ Structure
inner & Outer Drum body is constructed in AlSl - 304 stainless steel s All Contact Parts also made by 304 stainless steel with a viton seal. resistant to washing processes. We Designed the latest international complete TFT suspension structure to reduce shock, the original shock design by liquid pressure buffer with high grade springs. To ensure an ideal shock proof effect on higher floor design is based on the calculation of structural tensions to avoid critical points and achieve a very sturdy machine with a long service life even when operating under the most demanding conditions.
Technical Specification
Model | Capacity Kg | Cylinder size Kg volume | Drive Motor Kw | Cylinder Speeds | Wash Extract | Loading door opening | Base Tank 1 | Base Tank 2 | Pump 1 | Pump 2 | Filter surface area 1 | Filter surface area 2 | Overall dimensions (mm) | Approx weight9kg |
DCW 15 | 15 | 72 x 380 21'' 18'' 154 ltrs | 2.2 | 45 to 55 rpm | 900 rpm | 400 mm | 85 ltrs | 85 ltrs | 0.37 kw | 0.37 kw | 7600 cm2 | 7600 cm2 | 1050 x 1060 x 2050 | 850 |
DCW 30 | 30 | 900 x 500 38'' 19'' 318 ltrs | 5.5 | 45 to 55 rpm | 850 rpm | 500mm | 135 ltrs | 135 ltrs | 0.37kw | 0.37kw | 10900cm2 | 10900cm2 | 1350 x 1450 x 2200 | 1580 |
DCW 60 | 60 | 1100 x 650 43'' 25'' 618 ltrs | 10 | 45 to 55 rpm | 720 rpm | 650mm | 210ltrs | 210ltrs | 1.1 kw | 1.1 kw | 13800 cm2 | 13800 cm2 | 1650 x 1720 x 2650 | 2560 |
![]() |
